Battery Electric Pallet Stacker standing electric pallet jack 2500kg

  • 1
  • 2
  • 3

Brand Name : YONGJIELI

Model Number : CDD40

Certification : CE

Place of Origin : Anhui, China

MOQ : 1 SET

Price : $4,620.00~$4,950.00 PER SET

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 100 SETS PER MONTH

Delivery Time : 10 WORK DAYS

Packaging Details : EXPORT PACKING

Power type : Battery

Tire type : Polyurethane

Mast type : Duplex mast

Steering type : Electronic steering

Parking brake type : Electromagnetic braking

Name : Electric Pallet Stacker

Contact Now

Electric Pallet Stacker Standing American CURTIS Drive Control Germany Bucher Pump AC Drive Multifunctional Lever

Advantages:

  • Configuration and performance:
  • Wide angle view, high-strength shock absorption gantry
  • CURITS Brand Drive Control System in the United States
  • Zhongnan Transmission
  • Electronic steering, lightweight, silent
  • Shimadzu brand low noise hydraulic pumps and valves
  • Drive speed compensation short circuit and open circuit protection
  • Electromagnetic and regenerative braking system
  • High and low voltage limits, electrical overheating protection
  • Line fault detection and error code diagnosis
  • Torch brand 48V high capacity lead-acid battery

Security:

  • Automatic deceleration device for bends
  • Drive endless speed regulation
  • Controller multiple automatic protection system
  • Inductive safety seat
  • Cylinder safety shut-off valve
  • EPS AC
  • Low noise hydraulic pump
  • LED front headlights
  • Side pull battery

Name

Model No. CDD25
Power Supply Battery
Driving Mode Stand-on
Load 2500kg
Load Center Distance 500mm
Tyre Material Polyurethane
Tyre Amount 4/1x+2
Mast type Double
Standard Lift Height 3000 mm
Free Lift Height /
Lowered Mast Height 2000 mm
Loading MAX. Height 3490 mm
MIN. Grounding clearance 85 mm
Overall Length 2515 mm /2115 mm
Axis 1390 mm
Overall Width 1230 mm
Track Front/Rear 505 mm/1100 mm
Fork Size 1150 mm/200 mm/65 mm
Distance of Unilateral External Fork 685 mm/560mm
Turning Radius 2125mm/1715mm
Driving Velocity (full/idle) 4.0/5.0 Km/h
Lifting Velocity (full/idle) 80/125 mm/s
Descending Velocity (full/idle) 160/105 mm/s
Climbing Velocity (full/idle) 5%/8%
Drive Motor AC
Drive Motor Power 1.5 kw
Lifting Motor DC
Lifting Motor Power 3 kw
Battery 24 V/210 AH
Battery Weight 200 kg
Weight (including battery) 1300 kg
Steering Type Electronic Steering
Brake System Electromagnetic
Brake Mode Lever Operation
